Stoltzen THALIA PTZ5-NDI 12x 4K60 NDI|HX 60hz | SDI |  NDI | HDMI | USB2.0 Stoltzen THALIA PTZ5-NDI 12x 4K60 NDI|HX 60hz | SDI |  NDI | HDMI | USB2.0

Stoltzen THALIA PTZ5-NDI 12x 4K60 NDI|HX

60hz | SDI | NDI | HDMI | USB2.0

Varenr: 130912
Alt. varenr: PTZ5-NDI-12x
BeskrivelseTilbehørAlternativerEkstern Info
Beskrivelse

Stoltzen THALIA PTZ5 12x 4K60 NDI | HX

60hz | SDI |  NDI | HDMI | USB2.0



Key Features



4K Ultra HD Image

Built with SONY high quality CMOS sensor, with resolution up to 4K@60fps.



Optical Zoom Lens

12x optical zoom lens, with 80.4° FOV without distortion.12X optical zoom 80.4°wide-angle lens (PTZ5-12X-NDI), 25X optical zoom 59.2°wide-angle lens (PTZ5-25X-NDI), and 31X optical zoom 59° wide-angle lens (PTZ5-31X-NDI)



Leading Auto Focus Technology

Fast, accurate and stable auto focus is achieved with leading auto focus algorithm.



Low Noise and High SNR

Super high SNR image is achieved with low noise CMOS. The adoption of advanced 2D/3D noise reduction technology further reduces the noise while ensuring high image clarity.



Multiple video output interfaces

With video 4k output from HIMI, USB2.0 and LAN at the same time.



Multiple Audio/Video Compression Standard

Support H.264/H.265 video compression over LAN, support MJPG, H.264, YUY2 and NV12 over USB2.0 port, support AAC audio compression over A-in port. LAN interface supports H.264/H.265 video compression, USB2.0 interface supports MJPG ,H264 ,YUY2 ,NV12 ,H265; A-IN interface supports AAC audio compression coding.



Multiple Network Protocol

Support ONVIF, GB/T28181, RTSP, RTMP protocols; Support RTMP push mode, easy to be connected to streaming server (Wowza, FMS); Support RTP multicast mode; Support network full command VISCA control protocol.



Multiple Presets

Support up to 255 presets (10 presets by remote controller)





Technical Specification:



ModelPTZ5-12X-NDIPTZ5-25X-NDIPTZ5-31X-NDI
4K PTZ Camera
Image Sensor1/2.5-inch SONY CMOS Image Sensor1/1.8-inch SONY CMOS Image Sensor1/1.8-inch SONY CMOS Image Sensor
Focus f=3.85 mm~ 43.06 mm ±5%f=7.1 mm~ 171.95 mm ±5%f=6.91 mm~ 214.64 mm ±5%
Viewing AngleH:7.59°(N)~ 80.4°(W)H:2.5°(N)~ 59.2°(W)H:1.98°(N)~ 59°(W)
 V:4.6°(N)~ 50.0°(W)  V:1.4°(N)~ 34.6°(W)  V:1.12°(N)~ 34.14°(W)
Iris ValueF1.8 ~ F3.56±5%F1.61 ~ F5.19±5%F1.35 ~ F4.6±5%
Effective Pixel8.51M 16:9
Video SignalHDMI
3840*2160P60/50/25/59.94/29.97 ,1080P60/50/ 30/25/59.94/29.97 ,1080I60/50/59.94; 720P60/50/59.94
SDI
1080P60/50/30/25/59.94/29.97 ,1080I60/50/59.94 ,720P60/50/59.94
USB2.0
MJPG:3840*2160/1920*1080/1280*720 /1024*768  /1024*576/800*600/720*576/720*480/704*576/640*480 /640*360  /352*288/320*240P30
  H264:3840*2160/1920*1080/1280*720 /1024*768  /1024*576/800*600/720*576/720*480/704*576/640*480 /640*360  /352*288/320*240P30
  YUY2:800*448 /720*480P25 ,640*360 /432*240P30
  NV12:800*448P25 ,640*480 /640*360 /432*240P30
Optical Zoom12x25X31X
Digital Zoom15x15x15x
AIReal-time Tracking, Zone Tracking
Back PanelHDMI, SDI ,LAN(POE), USB2.0 ,A-IN ,RS232-IN ,RS232-OUT ,RS422(Compatible with RS485),
Rotary Dip Switch ,DC12V Power Supply, Power Switch
Accessory Power Adapter, RS232 Cable, USB2.0 Cable, Remote Control, User Manual
