Stoltzen PTZ3 – Full HD PTZ Camera with AutoTracking
The Stoltzen PTZ3 is a high-performance Full HD PTZ camera designed to deliver exceptional video quality and advanced tracking features. With a robust 1/2.8-inch CMOS sensor, innovative Ai AutoTracking technology, and multiple output options, the PTZ3 ensures seamless integration into professional environments such as conferences, classrooms, and live broadcasts.
Key Features
- 12x Optical Zoom: Capture every detail with high-quality optical zoom.
- Simultaneous Outputs: HDMI, IP, and USB 3.0 outputs deliver versatile connectivity options.
- PoE Support: Simplifies installation with Power over Ethernet.
- Remote Control: Comes with an intuitive remote for easy operation.
- Image Flip: Supports image flipping for flexible mounting options.
Highlights
Exceptional High-Resolution Image
Equipped with a 1/2.8-inch CMOS sensor, the PTZ3 provides resolutions up to 1920 x 1080 with frame rates of up to 60fps, ensuring crystal-clear and smooth video.
Advanced Autofocus Technology
The cutting-edge autofocus algorithm ensures fast, accurate, and stable focus, even in dynamic environments.
Revolutionary AutoTracking
Using advanced Ai technology, the camera automatically tracks faces and movements without requiring manual configuration or user intervention. Simply step into the frame, and the PTZ3 will follow your movements.
Low Noise and High Signal-to-Noise Ratio (SNR)
The low-noise CMOS sensor ensures an excellent SNR for video output. Additionally, 2D/3D noise reduction technology minimizes noise while maintaining sharp image quality.
Dual Stream Support via USB 3.0
The PTZ3 supports simultaneous mainstream and substream output, offering compatibility with formats like YUY2, MJPEG, H.264, NV12, and H.265.
Versatile Control Protocols
Supports multiple protocols, including VISCA, PELCO-D, and PELCO-P, with automatic protocol identification for seamless operation.
Quiet and Smooth PTZ Movement
The precision motorized mechanism ensures smooth pan, tilt, and zoom movements with minimal noise, even at low speeds.
Specifications
| Sensor | 1/2.8-inch high-quality CMOS sensor |
| Resolution | Up to 1920 x 1080 @ 60fps |
| Color | Black |
| Zoom | 12x Optical Zoom |
| Viewing Angle (°) | 72.5 |
| Video Format | H.264, H.265, MJPEG, YUY2 |
| Output Ports | HDMI, USB 2.0, USB 3.0, LAN |
| Control Ports | RS232, RS485, RJ45 |
| Audio Input/Output | Independent 3.5mm stereo jack |
| PoE Support | Yes |
| Power Supply | 12V 1A |
| Accessories | Power supply, RS232 control cable, USB 3.0 cable, remote control, user manual |
| Pan Rotation Angle | -170° to +170° |
| Tilt Rotation Angle | -30° to +90° |
| Pan Speed | 0.1° to 100°/sec |
| Tilt Speed | 0.1° to 45°/sec |
| Noise Reduction | 2D/3D Noise Reduction |
| Operating Temperature | -10°C to +50°C |
| Certifications | CE, REACH, RoHS |
| Dimensions | Standard |
| Weight | Approx. 1.5kg |
| Protocols | RTSP, RTMP, ONVIF, VISCA Over IP, PELCO-D, PELCO-P |
