Teltonika TRB255

INDUSTRIAL M2M GATEWAY NB-IOT - 4G LTE

Varunummer: 126529

Alt. varunr: TRB255000000

Beskrivning

TRB255

INDUSTRIAL M2M GATEWAY TRB255

TRB255 can be used to integrate modern and legacy industrial equipment into one solution via RS232, RS485 & Ethernet interfaces. This industrial LTE Cat M1 & NB-IoT gateway is backward compatible to EGPRS (2G) networks. It can still be used with 2G network, however in case it gets shut down, there is a possibility to switch to LPWAN connectivity options. TRB255 has a wide range of industrial and networking features such as Modbus, SMS control, Firewall, OpenVPN and more. This product is compatible with the Teltonika Networks Remote Management System (RMS).

PACKAGE CONTAINS

Gateway TRB255
9 W PSU
1 x Mobile antenna (swivel, SMA male)
1 x GNSS antenna (adhesive, SMA male, 3 m cable)
16 pin terminal block
1 x hex key
Ethernet cable (1.5 m)
QSG (Quick start guide)
RMS Flyer
Packaging box

HARDWARE

Mobile – 4G/LTE (Cat M1), NB-IoT, 2G

CPU - Qualcomm QCA9531, MIPS 24kc, 650 MHz

Storage - 16 MB Flash

Memory - 64 MB RAM

Powering Option - 16-pin terminal, 9-30 VDC

SIM – 2 x Internal SIM holders (2FF)

Antenna connectors – 1 x SMA for mobile, 1 x SMA for GPS

thernet - 1 x RJ45 port, 10/100 Mbps

GNSS – GPS, GLONASS, BeiDou, Galileo, QZSS

Inputs/Outputs - On 16-pin socket: 3 x Digital input/Digital open collector output (configurable), 1 x Analog input

Serial - 1 x RS232, 1 x RS485

Status LEDs - 3 x Connection type, 3 x Signal strength, 2 x Ethernet, 1 x Power

Operating temperature - -40 °C to 75 °C

Housing - Aluminum housing with DIN rail mounting option

Dimensions - 83 x 25 x 74.2 mm

Weight – 165 g

SOFTWARE

Operating system - RutOS (OpenWrt based Linux OS

Mobile features - Multiple PDN, Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits

Network - TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL)

Monitoring and management - WEB UI, CLI, SSH, CALL, SMS, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS

Connection monitoring - Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection

Cloud solutions - RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx

Serial - Console, Over IP, Modem, NTRIP, Modbus

Modbus - TCP slave, TCP master, RTU master, RTU gateway, Modbus over MQTT

GNSS – NMEA forwarding, AVL, Geofencing

Cloud solutions – RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx

Administration - Multi user, Configuration profiles, Diagnostics, logs, Configuration backup

NTP - NTP Server, NTP Client, Sync with: External NTP server, GNSS, Mobile operator
