Stoltzen 6100D Decoder
The Stoltzen Apollo 6100D Decoder is a versatile and high-performance AV-over-IP solution designed for seamless integration into modern video distribution systems. With support for resolutions up to 4K UHD at 60Hz and 4:4:4 chroma subsampling, it ensures outstanding video quality over standard gigabit Ethernet networks. Its compatibility with advanced audio formats, video wall configurations, and low-latency streaming makes it ideal for a wide range of applications, including professional AV setups, conference rooms, and digital signage.
The decoder features robust connectivity options, including HDMI and network-based input and output ports, enabling simple and efficient signal management. Additional features such as PoE support, advanced USB 2.0 functionality, and comprehensive control via apps or IP controllers make installation and operation hassle-free.
With a compact design, sturdy construction, and wide compatibility, the Apollo 6100D Decoder is built to deliver exceptional performance and reliability in demanding environments.
Key Features:
- 4K UHD Video Support: Supports resolutions up to 3840 x 2160p at 60Hz with 4:4:4 chroma subsampling.
- Low Latency: End-to-end latency of just 1 frame for smooth streaming.
- Audio Compatibility: Handles advanced audio formats, including Dolby Atmos, DTS:X, and PCM 7.1, with HDMI ARC and analog audio output.
- Video Wall Capability: Supports video wall configurations up to 16 x 16 screens.
- PoE+ Support: Power over Ethernet (PoE+) for simplified installation.
- USB 2.0 Over IP: High-performance USB support for peripherals like cameras, with enhanced power capabilities.
- Control Options: Easily manageable through Windows or iPad apps and IP controllers.
- Comprehensive Connectivity: HDMI input/output, S/PDIF, LAN/optical, and analog audio.
- Advanced Protocols: Supports Telnet, SSH, HTTP, and HTTPS for flexible communication.
- Compact Design: Slim and durable chassis for efficient installation.
Specifications
| Video | |
| Input Port | 1 x RJ-45 (IP Stream) |
| Input Type | IP Stream |
| Input Resolutions | Up to 3840 x 2160p @ 60Hz 4:4:4 |
| Output Port | 1 x HDMI type A (19 pins) |
| Output Type | HDMI 2.0a, HDCP 2.2/2.3 |
| Output Resolutions | Up to 3840 x 2160p @ 60Hz 4:4:4 |
| End-to-End Latency | 1 frame |
| Audio | |
| Input Ports | 1 x S/PDIF IN, 1 x LAN/Optical |
| Input Signal | S/PDIF IN: Digital audio |
| LAN/Optical: PCM 2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio, DTS:X |
| Output Ports | 1 x HDMI, 1 x 3.5mm stereo jack |
| Output Signal | HDMI: PCM 2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio, DTS:X |
| Audio Out: Analog |
| Control | |
| Control Methods | Windows App, iPad App, IP Controller (SA-C) |
| General | |
| Operating Temperature | +32°F ~ +113°F (0°C ~ +45°C), 10% ~ 90% non-condensing |
| Storage Temperature | -4°F ~ +158°F (-20°C ~ +70°C), 10% ~ 90% non-condensing |
| Power | 12 VDC 2 A, PoE+ |
| Power Consumption | 8.5W (Max) |
| ESD Protection | ±8 kV (air-gap discharge), ±4 kV (contact discharge) |
| Dimensions | 8.46'' x 0.98'' x 4.72'' (215 mm x 25 mm x 120 mm) |
| Net Weight | 1.63 lbs (0.74 kg) |
| Features | |
| HDCP Compliance | HDCP 2.2/2.3 |
| Video Wall Support | Up to 16 x 16 screens |
| USB Support | USB 2.0 for high-performance devices |
| PoE Support | Power over Ethernet (PoE+) |
| Audio Return Channel | HDMI ARC, bi-directional serial communication |
| DHCP | DHCP with AutoIP fallback |
| Protocols | Telnet, SSH, HTTP, HTTPS |
