Yealink AP08 Digital Signal Processor
The Yealink AP08 DSP is a high-performance digital signal processor designed to enhance audio experiences in meeting rooms. With advanced capabilities like dynamic AEC, intelligent noise cancellation, and reverberation suppression, it supports up to 16x16 Dante audio channels, along with 4x4 analog audio channels. Integrated with Yealink’s Room Designer software, it provides seamless audio routing and room-specific optimization. The AP08 DSP ensures clear communication and superior audio transmission for any meeting setup.
Key Features:
- 16x16 Dante Audio Channels: Includes 8 dynamic AEC channels for optimized audio clarity.
- Analog Channels: 4x4 analog audio channels with balanced and unbalanced options.
- USB Interface: Dual USB 3.0 Type-B ports for device integration.
- One-Button Deployment: Effortless plug-and-play setup with automatic audio link establishment.
- AI-Based Sound Optimization: Automatically adjusts audio settings for room acoustics.
- Seamless Integration: Compatible with Yealink's Teams meeting room solution for easy management.
Specifications
| Dante Input Channels | 16 (8 AEC channels) |
| Dante Output Channels | 16 |
| Frequency Response | 50-20KHz |
| THD+N | <1% |
| Sampling Rate | 48KHz |
| Bit Depth | 24bit |
| Dynamic Range | 86dB |
| Analog Input Channels | 2 * RCA (unbalanced), 2 * 3-pin (balanced) |
| Analog Output Channels | 2 * RCA (unbalanced), 2 * 3-pin (balanced) |
| Input Dynamic Range | 96dB |
| Output Dynamic Range | 98dB |
| Self-Noise | RCA: -94dBu, Analog: -86dBu |
| Phantom Power | +48VDC 10 mA max |
| USB Channels | 2 * USB input/output |
| Control Ports | RJ-45 (API control), RS232, GPIO (8-pin Phoenix), +12VDC |
| LAN Ports | 3 * RJ-45 (Dante network ports) |
| Power Supply | 100–240V, 50/60Hz, 2A |
| Dimensions (LWH) | 360mm x 189mm x 44mm |
| Weight | 2.2kg |
| Operating Temperature | 0–40°C |
| Operating Humidity | 0–93% RH |
| Rated Power | 105W (Full-load), 15W (No-load) |
| Storage Temperature | -30–70°C |
Product Accessories:
- Mounting Ear (Left/Right)
