Ubiquiti Unifi Access Ultra
Bult-in hub for 1 door
An access reader with a built-in hub for complete, single-door entry control from one device.
(1) Lock terminal (12V DC, 1A)
(1) Exit request input
Unlock using an NFC card or UniFi Identity mobile app
Connect and power using PoE+
IP55 weather resistance (-30 to 40° C)
SPECIFICATIONS
Mechanical
Dimensions | 126 x 45 x 37.45 mm (4.9 x 1.8 x 1.5 in) |
Weight | 140 g (4.9 oz) |
Enclosure Material | Polycarbonate, aluminum alloy |
Mounting | Wall mount, gang box mount |
Weatherproofing | IP55 |
Hardware
Dimensions |
126 x 45 x 37.45 mm (4.9 x 1.8 x
1.5 in) |
Weight |
140 g (4.9 oz) |
Enclosure Material |
Polycarbonate, aluminum alloy |
Mounting |
Wall mount, gang box mount |
Weatherproofing |
IP55 |
Networking Interface |
10/100 MbE RJ45 port |
Connectivity |
Ethernet, BLE 4.2 |
Digital Input |
(1) Exit request |
Lock Terminals |
(1) 12V DC, 1A |
Power Method |
PoE+ |
Max. Power Consumption |
18W |
ESD/EMP Protection |
Air: ±8kV, contact: ±4kV |
LEDs |
R/G/B/W |
Button |
(1) Factory reset |
Tamper Switch |
Yes |
Speaker |
Buzzer |
NFC Frequency |
13.56 MHz |
NFC Read Range |
< 50 mm |
NFC Standards |
ISO 14443A, 14443B, 15693 |
NFC Technology |
NFC Tag 1, 2, 3, 4, 5 |
MIFARE Support |
MIFARE Classic, MIFARE Plus, MIFARE Ultralight, MIFARE DESFire |
Ambient Operating Temperature |
-30 to 40°C (-22 to 104°F) |
Ambient Operating Humidity |
5 to 90% noncondensing |
Certifications |
CE, FCC, IC |
