Stoltzen SHE755
The Ultimate Video Extension Solution!
The SHE755 is the ultimate solution for video extension, utilizing 18Gbps HDBaseT 3.0 technology. It extends HDMI/USB-C signals up to 70 meters (4K30/1080P) or 40 meters (4K60) via a single CAT6A/7 cable. Enjoy 4K@60Hz 4:4:4 resolution and flexible connectivity. It's easy to install and integrate into various setups.
Features and Benefits:
- HDBaseT 3.0 Technology: High transfer speed of up to 18Gbps, enabling long-distance transmission over a single CAT6A/7 cable.
- Video Extension: Supports up to 70 meters for 4K30/1080P or 40 meters for 4K60.
- Resolution Support: Up to 4K@60Hz 4:4:4, offering excellent image quality with precise color reproduction.
- USB-C and HDMI Compatibility: Supports USB-C (with 60W charging) and HDMI for flexible connectivity.
- Control and Audio Support: Includes two-way IR, RS-232, and analog audio output (3.5mm jack).
- Easy Installation: Simplifies setup and integration into existing AV systems in commercial environments like conference rooms and classrooms.
Specifications
| Transfer Speed | Up to 18Gbps |
| Transfer Distance | 70 meters (4K30/1080P)
40 meters (4K60) |
| Supported Resolutions | Up to 4K@60Hz YUV 4:4:4 |
| Input Ports (Transmitter) | 1x HDMI
1x USB-C (with 60W charging capability)
1x USB Host
3x USB Devices |
| Output Ports (Receiver) | 1x HDMI
2x USB Devices |
| Analog Audio Support | 3.5mm analog audio output |
| Control Signals | Two-way IR, RS-232 |
| Power Supply | 24V DC |
