Hisense’s BM66AE Digital Signage Displays
Are perfectly fit for public transport and retail locations. Their slim body design will make them blend into their surrounding and make your on-screen messaging stand out. Their vivid and vibrant colors immerse viewers and will effectively provide them with the information they are looking for.
All this with the flexibility and reliability that are required for round-the-clock broadcasting locations due to light sensors, intelligent temperature control and dual-core SOC technology for PC-less offline or cloud based content management. You can rest assure your content will be delivered 24/7 in an elegant, vibrant and reliable way."
FEATURES
COMPONENTS
• HDMI
CEC support through HDMI
•
Remote control IR loop (with RJ45)
•
Firmware upgrade via
USB/Network
• 24/7
Scheduler with Real Time Clock
• Over
temperature protection
User Remote
•
Remote controller lock
manual controller
•
Key lock
•
Built-in 8W x 2 speakers
• Fast
standby
• World
Clock setting
Logo Power
•
Wake up on LAN
accessory
cord
•
Wireless Access Point for mobile devices |
Digital
Signage Displays: M-series |
|
Model |
49BM66AE |
Panel |
Backlight |
ELED |
Size |
|
Resolution |
3840*2160 |
Refresh rate |
60HZ |
Color |
1.07B |
Brightness |
500nits |
Contrast(typ) |
1100:1 (typ) |
Response
time(typ) |
8ms |
Viewing
angle(Min.) |
178°/178° |
Color gamut |
72% |
Haze |
1% |
Orientation |
Landscape & Potrait |
MTBF |
50000hrs |
Operation
Hours |
7Day*24Hour |
System |
OS |
Android 7.0 |
CPU |
ARM Cortex-A73 Dual core |
GPU |
Mali 450 |
DDR |
2G |
ROM |
16G |
Language |
English/Chinese |
Connectivity |
WIFI |
Yes |
LAN |
RJ45×1 |
SD /TF Card |
/ |
Input |
HDMI*1/DVI*1/VGA*1 |
/DP*1/USB*1/RS232*1 |
Output |
DVI*1/RS232*1 |
Speaker |
Built in speaker |
8W*2 |
Control Method |
Remote |
Yes |
RS232 |
Yes |
Environment |
Temperaturer |
Storage:-20°~60° |
Operation:0°~40° |
Humidity |
Storage:-10%~90% |
Operation:10%~80% |
Power |
Input |
AC 100~240V(50/60Hz) |
Power
Consumption |
100W(Max) |
Standby
Consumption |
<0.5W |
Physical |
Bezel Color |
Black |
Set
Dimension(WxHxD) |
1105×639×64.5mm |
Bezel width
(T/L/R/B) |
11.9mm(T),15.4mm(B),12.4m-
m(L/R) |
Net Weight |
17kg |
Packing
Dimension (WxHxD) |
1208×199×748mm |
Packed
Weight |
17kg |
VESA |
300*300mm |
Bitmap
|
Bitmap
|
CB,CE,ERP |
Media Player compability |
OPS Type Compatible |
Yes |
Accessories |
Basic |
Power cord\Remote Control\
Battery\LOGO |
