ACT-311B/ACT-32H komplett trådløst mikrofon sett, mottager med håndmikrofon/sender ACT-32H.

Mipro ACT-311B

CPU-controlled diversity receiving. "PiloTone & NoiseLock" dual-squelch circuit eliminates signal drop-out and minimizes interference.
All controls are intuitive and easily operated via electronic buttons to prevent accidental operation.
Industry’s only RF interference warning indicator for proper adjustments of the SQ level. Increase sensitivity to extend receiving range; decrease the sensitivity to reduce interference.
Auto Scan function allows quick search for an interference-free working channel. World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
Output level is pre-adjusted to equal the microphone capsule’s sensitivity. Switchable output levels for the best sound quality options.
Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.

Channel	Single
	Chassis	EIA Standard 19 " 1/2U metal chassis
	Display	Green backlit LCD with automatic bright (working) and dim (standby) displays during performance.
	Frequency Range	UHF 480 ~ 934 MHz (country dependent)
	Bandwidth	24 MHz
	Deviation	< ± 40 kHz
	Receiving Mode	CPU-controlled diversity receiving
	Sensitivity	10 dBµV at S/N > 80 dB
	S/N Ratio	> 106 dB(A)
	T.H.D.	< 0.5% @ 1 kHz
	Frequency Response	50 Hz ~ 18 kHz
	Squelch	“PiloTone & NoiseLock” dual-squelch circuit
	Audio Output	Balanced XLR & Unbalanced Ø 6.3 mm
	Max. Output Level	Balanced: 0 dBV ; Unbalanced: +10 dBV / 0 dBV
	Power Supply	12 ~ 15 V DC, 1A
	Dimensions (W × H × D)	210 × 44 × 180 mm / 8.3 × 1.7 × 7.1 "
	Net Weight	Approx. 0.8 kg / 1.8 lbs

Mipro ACT-32H

Innovatively designed metal housing in MIPRO’s distinctive aesthetic and ergonomic style.
Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers. The unique multi-layered metal grille protects the capsule against impact, rolling and pop noise, ensuring clarity of sound. The upper grille is easy to detach for cleaning and hygiene practice.
Patented capsule suspension design virtually eliminates vibration and handling noises.
Built-in high-efficiency antenna.
Backlit LCD displays all operational parameter information.
World’s first ACT™ function provides precise and rapid frequency sync to the receiver.

Housing	Black-color rugged plastic housing
	Display	LCD displays all operational parameter information.
	Frequency Range	UHF 480 ~ 934 MHz (country dependent)
	Bandwidth	24 MHz
	RF Output Power	10 ~ 30 mW (country dependent)
	Deviation	< ± 40 kHz
	Spurious Emissions	< -55 dBc
	Gain	0 dB = input microphone sensitivity. High-fidelity modulation circuit sustains high SPL without distortion.
	Dimensions (Ø × L)	51 × 234 mm / 2 × 9.2 "
	Net Weight	Approx. 251 g / 8.9 oz
	Battery	2 × AA alkaline
	Operating Time	Min. 12 hours

Antall artikler funnet:

Mipro ACT-311B/ACT-32H

Håndsett 8A-D (822~832MHz)

Varunummer: 119890

Alt. varunr: 560234

Beskrivning

ACT-311B/ACT-32H komplett trådløst mikrofon sett, mottager med håndmikrofon/sender ACT-32H.

Mipro ACT-311B

CPU-controlled diversity receiving. "PiloTone & NoiseLock" dual-squelch circuit eliminates signal drop-out and minimizes interference.
All controls are intuitive and easily operated via electronic buttons to prevent accidental operation.
Industry’s only RF interference warning indicator for proper adjustments of the SQ level. Increase sensitivity to extend receiving range; decrease the sensitivity to reduce interference.
Auto Scan function allows quick search for an interference-free working channel. World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
Output level is pre-adjusted to equal the microphone capsule’s sensitivity. Switchable output levels for the best sound quality options.
Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.

Channel	Single
	Chassis	EIA Standard 19 " 1/2U metal chassis
	Display	Green backlit LCD with automatic bright (working) and dim (standby) displays during performance.
	Frequency Range	UHF 480 ~ 934 MHz (country dependent)
	Bandwidth	24 MHz
	Deviation	< ± 40 kHz
	Receiving Mode	CPU-controlled diversity receiving
	Sensitivity	10 dBµV at S/N > 80 dB
	S/N Ratio	> 106 dB(A)
	T.H.D.	< 0.5% @ 1 kHz
	Frequency Response	50 Hz ~ 18 kHz
	Squelch	“PiloTone & NoiseLock” dual-squelch circuit
	Audio Output	Balanced XLR & Unbalanced Ø 6.3 mm
	Max. Output Level	Balanced: 0 dBV ; Unbalanced: +10 dBV / 0 dBV
	Power Supply	12 ~ 15 V DC, 1A
	Dimensions (W × H × D)	210 × 44 × 180 mm / 8.3 × 1.7 × 7.1 "
	Net Weight	Approx. 0.8 kg / 1.8 lbs

Mipro ACT-32H

Innovatively designed metal housing in MIPRO’s distinctive aesthetic and ergonomic style.
Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers. The unique multi-layered metal grille protects the capsule against impact, rolling and pop noise, ensuring clarity of sound. The upper grille is easy to detach for cleaning and hygiene practice.
Patented capsule suspension design virtually eliminates vibration and handling noises.
Built-in high-efficiency antenna.
Backlit LCD displays all operational parameter information.
World’s first ACT™ function provides precise and rapid frequency sync to the receiver.

Housing	Black-color rugged plastic housing
	Display	LCD displays all operational parameter information.
	Frequency Range	UHF 480 ~ 934 MHz (country dependent)
	Bandwidth	24 MHz
	RF Output Power	10 ~ 30 mW (country dependent)
	Deviation	< ± 40 kHz
	Spurious Emissions	< -55 dBc
	Gain	0 dB = input microphone sensitivity. High-fidelity modulation circuit sustains high SPL without distortion.
	Dimensions (Ø × L)	51 × 234 mm / 2 × 9.2 "
	Net Weight	Approx. 251 g / 8.9 oz
	Battery	2 × AA alkaline
	Operating Time	Min. 12 hours
