LinkIT Cat.6 U/UTP Outdoor kabel 305m

PVC inner PE outer UV rated AWG 23 Svart

Varunummer: 50564
Alt. varunr: LT-ODC6-305
BeskrivningTeknisk infoTillbehörExtern Info
Beskrivning

LinkIT Cat.6 U/UTP Outdoor Cable 305m

PVC inner | PE outer | UV rated | AWG 23 Black



Outdoor Cat.6 cable with outer UV-resistant sheath that allows the cable to be used outdoors. Can handle a mimimum of 250MHz band width. The cable is specially designed for open installation.. Due to a solid sheath, the cable can also be stapled to the wall with staples. Fire class Eca. The cable is certified according to the new CPR directive

  • Specifically designed for open installation
  • Due to a solid sheath, the cable can also be stapled to the wall with staples.
  • Certified according to the new CPR directive
  • Can handle a mimimum of 250MHz band width
  • Fire class Eca



Main Specifications

Length (m)

305

Cable type

U/UTP

Color

Black

Category

Cat.6

Brand

LinkIT

Conductor material

Copper

Cable shielding

U/UTP – unshielded/unshielded twisted pairs



Extended Specifications

AWG wire size

23

Transmission speed

1000Mbps

Frequency (Mhz)

250

NVP value

69%

Jacket material

PE

Inner cape

PVC

Conductor diameter

0,490mm

Outer Cape diameter

7,3mm

Halogenfree

No

Core color 1

Blue, White

Core color 2

White, Orange

Core color 3

Green, White

Core Color 4

Brown, White

EAN

7072662004873

Certifications

CE, RoHS

Segregation Class

C

Teknisk info

Produktinformasjon

EL-nummer 6919464
Färg Svart
Kabelkategori Cat.6
Längd 305 m
Ytterhölje PVC
