LinkIT MTP/MPO-B OM4 8c USConec MTP Elite female - 8xLC | LSZH LinkIT MTP/MPO-B OM4 8c USConec MTP Elite female - 8xLC | LSZH

LinkIT MTP/MPO-B OM4 8c

USConec MTP Elite female - 8xLC | LSZH

Varunummer: 135608
Alt. varunr: MPO12-4XLCDPM4-xx
BeskrivningTeknisk infoExtern Info
Beskrivning

LinkIT QSFP+/MPO-B OM4 8xLC Magenta 10m

USConec MTP Elite female - 8xLC | LSZH



Breakout Cable for use in network infrastructure

  • Speed up to 40Gbit

To disconnect the QSFP + 40Gbps MPO transceiver to 4 x 10Gbps. USConec MTP Elite contact. Insertion Loss 0.1dB Typical, 0.35dB Max, Return Loss> 60dB. MTP for 4 x LC duplex, 8 fiber.



Main Specifications

Length (m)

10

Color

Magenta

Category

MTP/MPO

Brand

LinkIT

Connector type 1

QSFP+/MPO-B OM4

Connector type 2

8xLC

Network cable type

Network cable



Extended Specifications

Transmission speed

40Gbps

Halogenfree

Yes

SFP Coding

TX/RX 1,2,3,4 – 9,10,11,12

Bending radius (mm)

7,5

Temperature

0 to 70°C (32 to 158°F)

Certifications

CE, RoHS

Teknisk info

Produktinformasjon

Kontakter USConecElite MTP Female - 8xLC
Poleringstype UPC
Ytterhölje LSZH
