Lande IP65 Outdoor 16U W600xD650xH880

Metal doors | 19" | 500kg | Grey

Explore the cutting-edge IP65 Industrial Enclosures for IT-Systems, designed with precision to cater to diverse needs. These free-standing enclosures come in two depth variants: W600 x D650 (mm) and W600 x D800 (mm), offering flexibility to suit various applications. With a total of 7 height options ranging from 09U to 26U, you have the freedom to choose the perfect fit for your requirements.

Crafted for durability in challenging environments, the Lande OD series enclosures are constructed using materials that exhibit different levels of resistance to corrosive agents, humidity, and salty environmental effects often encountered in seaports. Material options include high-grade AISI 304, 316L, and 430 stainless steel.

Embodying a double-layer structure, these enclosures feature insulation material between the external and internal layers, ensuring optimal protection. The RAL7035 polyester outdoor type paint provides a sleek finish, with an optional RAL 9003 Signal White Polyurethane finish that is anti-graffiti and insul-paint applicable.

Engineered to meet IP65 Protection Level (EN60529) standards, these enclosures also conform to Nema-250 classifications 3, 3S, 4, 4X, 5,12,12K,13, demonstrating their resilience in challenging conditions. The polyurethane-infused sealing system further enhances the IP level, providing a robust solution for your industrial needs. Choose reliability and longevity with Lande OD series enclosures, tailored to exceed expectations in diverse and demanding environments.

1. Inner Door with Lockable Mechanism:

   • Front side includes an inner door that adds an extra layer of security.
   • The inner door is lockable, providing enhanced protection against unauthorized access.
   • Acts as a safeguard, particularly preventing dust entry when the main door is not locked.

2. Optional Door Sensors:

   • The cabinet can be equipped with either mechanical or magnet door sensors based on specific requirements.

3. Ventilation and Filter System:

   • Inner skin features a wingnut for easy manual opening, eliminating the need for tools.
   • Includes a ventilation channel and a replaceable filter location for efficient airflow and dust filtration.

4. Cable Entry Points:

   • Bottom case provides multiple access points with 2xPG21 and 1xPG48 integrated cable entry parts.
   • 2 pcs 28 mm diameter PVC Blind caps included, replaceable with PG21 cable entry parts as an option.
   • Encourages sealing openings with foam or isolation material after cable insertion.

5. Customizable Cable Entry Panel:

   • All IP65 cabinets come with a plain metal cable entry panel for customization.
   • Allows punching on the spare cable entry panel if the shipping configuration is not suitable for the project.

6. Hinged Canopy Roof:

   • Equipped with a hinged canopy roof with a mechanism to keep it open during installation and maintenance.
   • The canopy is gasketed for EN 60529 protection, ensuring a secure enclosure for the fan module.

7. Efficient Heat Discharge:

   • Hidden ventilation louvers allow fans to discharge hot air from the enclosure while maintaining EN 60529 IP65 protection.

8. Accessible Plinth Design:

   • Front and rear sides of the plinth have screwed metal panels for easy access during installation and maintenance.
   • Provides access to plinth concrete basement fixings and routed cables to the cabinet.
