General |
Model:
49WF45H |
Screen
size: 49" |
Screen
Active Area(mm): 1073.8x604.0 |
Resolution
: FHD(1920x1080) |
Aspect
Ratio: 16:9 |
Brightness(nit):
4500nits |
Contrast
Ratio: 1300:1 |
Dynamic
CR: Up to 450000:1 |
Viewing
Angle(H/V): 178°/178° |
Backlight
Life Cycle: 50,000 Hrs |
Operation
Hours: 24/7 |
Response
Time: 8ms |
Screen
Orientation: Portrait or Landscape |
|
System |
OS:
Android 9.0 |
CPU: ARM
Quad Core Cortex-A53 1.5G |
GPU: Arm
Mali-G52 2EE MC1 |
DDR: DDR
2GB |
ROM:
16GB EMMC |
Language:
Chinese/English |
|
Connectivity |
Input:
USB2.0 x2, HDMI IN x2, Ethernet RJ45 x2, RS232 RJ45 x1, IR in x1, Sensor x1 |
Output:
HDMI Out x1, Audio out x1 |
|
Network
connection |
Wifi or
LAN: Yes |
3G/4G
connection: Optional |
|
Speaker |
Build in
speaker: Yes |
Line-out
Support: Yes |
BT
Speaker Support: Yes |
|
Thermal
management |
Smart
Backlight Control: Yes |
Smart
Temperature Control: Yes |
Smart
Fans Control: Fanless |
Smart
Monitoring System Cloud: Optional / CetusMSC |
Overheating
protection: Yes |
|
Physical |
IP
rating: IP5X (Front Panel) |
Glass:
No |
Shell:
Aluminum |
Standard
Color: Black |
Bezel
width(T/L/R/B): 10mm(T/B/L/R) |
Dimensions
(H x W x D): 1096.18 x 626.4 x 56.75mm |
Packing
Dimensions(W × H × D): 1224 x 759 x 180mm |
VESA:
300 x 300 |
|
Operation |
Working
environment: Indoor window facing |
Auto
Brightness control: Light sensor |
Operation
Temperature (ambient temp.): -10oc to 35oc (Direct Sunlight) -10oc to 45oc
(w/o Direct Sunlight) |
Operation
Humidity: 10% to 80% |
Storage
Temperature: -10oc to +60oc |
Storage
Humidity: 10% to 80% |
|
Power |
Power
Supply: AC 110 /220V,50/60Hz |
Power
Type: Built-In Power |
|
What’s
in the box |
Accessories:
Power cord \ IR receiver \ Remote Control \ AAA batteries x2 \ Wifi antenna \
Lifting ring(M6) x2\ Filler pad(M6) x2 \ Spring pad(M6) x2 \ User
manual(Electronic version) |
