Netgear GSM4230P AV Line M4250

30-Port | 24xPoE+ 300W | 2x1G | 4xSFP

Switching engineered for 1G AV over IP with rear-facing ports ensuring a clean integration in AV racks. Pre-configured for out of the box functionality!

Pre-configured for out-of-the-box use

NETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installations

Video profiles built-in

Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed

Dedicated AV web-based GUI interface

Unique interface designed for the AV professional with color-coded, port-based profiles

Unique Automatic Configuration

Auto-trunk and auto-lag functionality automatically configures other M4250 switches for use in star topology.

Profiles for common audio protocols

Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate license

PHYSICAL SPECIFICATION

Dimensions (WxDxH) : 440 x 257 x 43.2 mm
Weight : 4.3Kg (9.47lb)

TECHNICAL SPECS

Primary Port Speed : 1 Gigabit
Number of Ports : 30 (24x 1G PoE+, 2x 1G, 4x SFP)
PoE Ports / Budget : 24 PoE+ (30W/port), 300W Budget
IGMP Support : Enhanced (NETGEAR IGMP Plus™)
Jumbo Frame Support : Yes, up to 12kb
AVB Support : Yes. Electronic license required, activation key sent via email (AVB4230P-10000S).
Acoustics : Fanless or 34dB@25ºC
Power Consumption : With PoE: 401W/1369.01Btu/hr
Without PoE: 35.8W/122.22Btu/hr
Standby without any port connection: 23.4W/79.89Btu/hr
