Mipro ACT-311B/ACT-32HC, MP8lader 8A-D 822~832MHz

Mipro ACT-311B/ACT-32H Håndsett 8A-D (822~832MHz) inkludert batteri og lader MP-8

ACT-311B/ACT-32C komplett trådløst mikrofon sett, mottager med håndmikrofon/sender ACT-32HC.

Mipro ACT-311B

CPU-controlled diversity receiving. "PiloTone & NoiseLock" dual-squelch circuit eliminates signal drop-out and minimizes interference.
All controls are intuitive and easily operated via electronic buttons to prevent accidental operation.
Industry’s only RF interference warning indicator for proper adjustments of the SQ level. Increase sensitivity to extend receiving range; decrease the sensitivity to reduce interference.
Auto Scan function allows quick search for an interference-free working channel. World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
Output level is pre-adjusted to equal the microphone capsule’s sensitivity. Switchable output levels for the best sound quality options.
Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.

Channel	Single
	Chassis	EIA Standard 19 " 1/2U metal chassis
	Display	Green backlit LCD with automatic bright (working) and dim (standby) displays during performance.
	Frequency Range	UHF 480 ~ 934 MHz (country dependent)
	Bandwidth	24 MHz
	Deviation	< ± 40 kHz
	Receiving Mode	CPU-controlled diversity receiving
	Sensitivity	10 dBµV at S/N > 80 dB
	S/N Ratio	> 106 dB(A)
	T.H.D.	< 0.5% @ 1 kHz
	Frequency Response	50 Hz ~ 18 kHz
	Squelch	“PiloTone & NoiseLock” dual-squelch circuit
	Audio Output	Balanced XLR & Unbalanced Ø 6.3 mm
	Max. Output Level	Balanced: 0 dBV ; Unbalanced: +10 dBV / 0 dBV
	Power Supply	12 ~ 15 V DC, 1A
	Dimensions (W × H × D)	210 × 44 × 180 mm / 8.3 × 1.7 × 7.1 "
	Net Weight	Approx. 0.8 kg / 1.8 lbs

Mipro ACT-32HC

Innovatively designed metal housing in MIPRO’s distinctive aesthetic and ergonomic style.
Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers. The unique multi-layered metal grille protects the capsule against impact, rolling and pop noise, ensuring clarity of sound. The upper grille is easy to detach for cleaning and hygiene practice.
Patented capsule suspension design virtually eliminates vibration and handling noises.
Built-in high-efficiency antenna.
Backlit LCD displays all operational parameter information.
World’s first ACT™ function provides precise and rapid frequency sync to the receiver.

Housing	Black-color rugged plastic housing
	Display	LED indicator for battery status.
	Frequency Range	UHF 480 ~ 934 MHz (country dependent)
	Bandwidth	24 MHz
	RF Output Power	10 ~ 30 mW (country dependent)
	Deviation	< ± 40 kHz
	Spurious Emissions	< -55 dBc
	Gain	0 dB = input microphone sensitivity. High-fidelity modulation circuit sustains high SPL without distortion.
	Dimensions (Ø × L)	51 × 250 mm / 2 × 9.8 "
	Net Weight	Approx. 251 g / 8.9 oz
	Battery	1 × ICR 18500 lithium battery
	Operating Time	Min. 13 hours
	Charger	MP-80 / MP-8

Mipro MP-8

The MP-8 is an intelligent single-slot charger providing efficient and safe charging, designed exclusively for MIPRO’s rechargeable handheld / bodypack transmitters. In addition to providing both quick and trickle charging, it has a reverse polarity protection circuit to prevent charging errors and shows the precise charging status with easily read indicators.

Compatible Transmitter	Rechargeable Handheld & Bodypack
	Input Voltage Range	DC 10 ~ 15 V / 1A
	Battery	ICR 18500 3.7 V Li-ion battery
	Charge Current	Approx. 500 mA by regulation current
	Current Consumption	Approx. 600 mA / 12 V, for two batteries charging at the same time
	Charge Method	Termination by 20% regulation current
	Function	For charging one handheld or bodypack transmitter
	Dimensions (W × H × D)	92 × 74.5 × 87 mm / 3.6 × 2.9 × 3.4 "
	Weight	Approx. 240 g / 8.5 oz

Mipro ACT-311B/ACT-32HC, MP8 lader 8A-D 822~832MHz

Accessories

Alternatives

Articles

Number of articles found:

Mipro ACT-311B/ACT-32HC, MP8

lader 8A-D 822~832MHz

Product nr: 119892

Alt. varunr: 560260

Description

Mipro ACT-311B/ACT-32H Håndsett 8A-D (822~832MHz) inkludert batteri og lader MP-8

ACT-311B/ACT-32C komplett trådløst mikrofon sett, mottager med håndmikrofon/sender ACT-32HC.

Mipro ACT-311B

CPU-controlled diversity receiving. "PiloTone & NoiseLock" dual-squelch circuit eliminates signal drop-out and minimizes interference.
All controls are intuitive and easily operated via electronic buttons to prevent accidental operation.
Industry’s only RF interference warning indicator for proper adjustments of the SQ level. Increase sensitivity to extend receiving range; decrease the sensitivity to reduce interference.
Auto Scan function allows quick search for an interference-free working channel. World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
Output level is pre-adjusted to equal the microphone capsule’s sensitivity. Switchable output levels for the best sound quality options.
Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.

Channel	Single
	Chassis	EIA Standard 19 " 1/2U metal chassis
	Display	Green backlit LCD with automatic bright (working) and dim (standby) displays during performance.
	Frequency Range	UHF 480 ~ 934 MHz (country dependent)
	Bandwidth	24 MHz
	Deviation	< ± 40 kHz
	Receiving Mode	CPU-controlled diversity receiving
	Sensitivity	10 dBµV at S/N > 80 dB
	S/N Ratio	> 106 dB(A)
	T.H.D.	< 0.5% @ 1 kHz
	Frequency Response	50 Hz ~ 18 kHz
	Squelch	“PiloTone & NoiseLock” dual-squelch circuit
	Audio Output	Balanced XLR & Unbalanced Ø 6.3 mm
	Max. Output Level	Balanced: 0 dBV ; Unbalanced: +10 dBV / 0 dBV
	Power Supply	12 ~ 15 V DC, 1A
	Dimensions (W × H × D)	210 × 44 × 180 mm / 8.3 × 1.7 × 7.1 "
	Net Weight	Approx. 0.8 kg / 1.8 lbs

Mipro ACT-32HC

Innovatively designed metal housing in MIPRO’s distinctive aesthetic and ergonomic style.
Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers. The unique multi-layered metal grille protects the capsule against impact, rolling and pop noise, ensuring clarity of sound. The upper grille is easy to detach for cleaning and hygiene practice.
Patented capsule suspension design virtually eliminates vibration and handling noises.
Built-in high-efficiency antenna.
Backlit LCD displays all operational parameter information.
World’s first ACT™ function provides precise and rapid frequency sync to the receiver.

Housing	Black-color rugged plastic housing
	Display	LED indicator for battery status.
	Frequency Range	UHF 480 ~ 934 MHz (country dependent)
	Bandwidth	24 MHz
	RF Output Power	10 ~ 30 mW (country dependent)
	Deviation	< ± 40 kHz
	Spurious Emissions	< -55 dBc
	Gain	0 dB = input microphone sensitivity. High-fidelity modulation circuit sustains high SPL without distortion.
	Dimensions (Ø × L)	51 × 250 mm / 2 × 9.8 "
	Net Weight	Approx. 251 g / 8.9 oz
	Battery	1 × ICR 18500 lithium battery
	Operating Time	Min. 13 hours
	Charger	MP-80 / MP-8

Compatible Transmitter	Rechargeable Handheld & Bodypack
	Input Voltage Range	DC 10 ~ 15 V / 1A
	Battery	ICR 18500 3.7 V Li-ion battery
	Charge Current	Approx. 500 mA by regulation current
	Current Consumption	Approx. 600 mA / 12 V, for two batteries charging at the same time
	Charge Method	Termination by 20% regulation current
	Function	For charging one handheld or bodypack transmitter
	Dimensions (W × H × D)	92 × 74.5 × 87 mm / 3.6 × 2.9 × 3.4 "
	Weight	Approx. 240 g / 8.5 oz
