HH Speaker Tessen TNi-W4-WH White
4" + 1" 30W@100V 45W@8 Ohm Phoenix
The TNi-W4 delivers professional audio output and versatility within a compact, wall mount speaker enclosure. The TNi-W4 - 4 inch passive enclosure - features 4 power tappings ranging from 1.5W - 30W and can be connected to 70V/100V or 8 ohm low impedance lines. Equipped with euroblock and M4 screw terminals, The TNi-W4 offers a wide array of connections within a single unit. With solid steel, multi-angle bracket included, The TNi-W4 comes with all essential installation components.
| 100V Power Options |
30W, 15W, 6W, 3W |
| 70V Power Options |
15W, 7.5W,
3W, 1.5W |
| Frequency Response (-10) |
80Hz >
20KHz |
| Frequency Response (-3) |
125Hz -
18KHz |
| LF Driver |
4 Inch
Paper |
| HF Driver |
1 Inch Dome
Tweeter |
| Low Nominal System Impedance |
8 Ohm |
| Power |
45W AES,
180W Peak |
| Max SPL (1M) (Peak) |
111 dB SPL |
| Sensitivity (1W/1M) |
88 DB SPL |
| Recommended Amplifer |
80-160W @ 8
Ohms |
| Horiz. Dispersion Angle 1000Hz |
90° |
| Vertical Dispersion Angle 1000Hz |
80° |
| Input Connector |
EUROBLOCK
AND M4 TERMINALS |
| Link Connector |
EUROBLOCK
AND M4 TERMINALS |
| Mounting Bracket |
ADJUSTABLE
STEEL BRACKET INCLUDED |
| Unit Dimensions (Hwd) |
295 X 145 X
222MM, 11.6" X 5.7" X 8.7" |
| Unit Weight |
2.8KG, 6.2
LBS |
| Main Construction Material |
ABS PLASTIC |
| Grille |
White Circular
mesh |
