Digital Projection E-Vision Laser 10000i

1920x1200, 9600 lumen

Varunummer: 132920
Alt. varunr: 123-528
BeskrivningTillbehörExtern Info
Beskrivning

E-Vision 10000i WU

1920x1200 | 9600 lumen



The all new E-Vision 10000i boasts 9,600 lumens brightness and 20,000:1 dynamic contrast, and shares the same advanced capabilities usually reserved for high-end 3-Chip products, such as Source Redundancy, Brightness Sync and Auto White Balance Correction, making these some of the most capable, flexible Single-Chip DLP projectors on the market today.

The E-Vision 10000i boasts stable 24/7 operation via efficient heat dissipation and excellent thermal conductivity ensures peak-performance and reliability.



Colour System:

Laser Phosphor

Display Type:

1 x 0.67" DarkChip™ DMD™

DMD Specification:

1920 x 1200 pixels native display.
Fast transit pixels for smooth greyscale and improved contrast.

Aspect Ratio:

16x10

Fill Factor

87 %

Key Features:

Video & Graphics Processing
HDMI 2.0
DisplayPort 1.2
Side by Side, Frame Packing, Frame Sequential, TopBottom and Dual Pipe 3D Formats.
Syncronisation of active glasses or polarising switcher.
DICOM simulation mode (For non-diagnostic or training)
HDR support
2D Smear reduction
Geometry Correction
Vertical & Horizontal Keystone correction
Four Corner adjustment
Selectable aspect ratios: 5:4 / 4:3 / 16:10 /16:9 / 1.88 / 2.35 / TheaterScope / Source / Unscaled
Digital Zoom
HDBaseT Interface
Built in support for transmission of uncompressed High Definition Video over standard CAT5e/6 LAN cable.
Allows the projector to be placed up to 100m from the source with low cost cabling.
HDBaseT® Includes Ethernet 100BaseT and RS232/IR control.
Colour Processing
Phosphor wheel: 2 x 7200rpm (120Hz)
Colour wheel: 4 Segment RGBY 2 x 7200rpm (120Hz)
10-bit colour processing (30-bits per pixel) 1,073,741,824 colours
Powerful seven point colour correction for accurate colour matching.


Source Compatibility

Graphics standards: Up to WUXGA 1920 x 1200 - 120Hz RB

Inputs/Outputs

Video & Computer
Type Connector Qty
HDMI 2.0 HDMI 2
DisplayPort 1.2 DisplayPort 2
HDBaseT 8P8C "RJ45" 1
3G-SDI in BNC 1
3G-SDI out BNC 1
.
Communication & Control
Type Connector Qty
3D Sync In BNC 1
3D Sync Out BNC 1
3D Sync IR BNC 1
LAN / Art-Net EtherCON RJ45 1
HDBaseT/Ethernet/RS232/IR RJ45 1
Serial In RS-232C 9-pin D-Sub 1
Serial Out RS-232C 9-pin D-Sub 1
Wired Remote In 3.5mm Stereo Jack 1
Wired Remote Out 3.5mm Stereo Jack 1
12V Trigger 3.5mm Stereo Jack 1
USB Power out 5V/2A USB Type A 1

3D Formats Supported

Frame Packing
Dual Pipe
Frame Sequential
Side By Side (half)
Top and Bottom

HDTV Formats Supported

SDTV (480i, 576i), EDTV (480p, 576p), HDTV (720p, 1080i, 1080p), NTSC (M, 3.58/4.43 MHz), PAL (B,D,G,H,I,M,N), SECAM (B,D,G,K,K1,L) Display Support for 2K 2048 x 1080 up to 60Hz and 4K-UHD 3840 x 2160 up to 60Hz

Computer Compatibility

VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA@60hz, Mac

Remote Control

Infrared Remote Control Unit

Automation Control

LAN - Webpage control
TCP/UDP control
RS-232
Alert Mail for Projector
LAN Control-Crestron® Connected
LAN Control-PJ Link Class 1 compatible
LAN Control-AMX® Device Discovery
Art-Net (DMX) control

Colour Temperature

User selectable (3200K/ 5400K / 6500K / 7500K / 9300K / Native )

illumination Type

Laser Phosphor

Typical illumination Life

20,000 hours

Lens

Lens Part No. Optimised Focus Range* Lens Shift (Frame)
0.38 :1 fixed 117-341 0.68m - 2.44m Depends on image size, see Installation Guide.
0.75 - 0.93 :1 zoom 115-339 1.02m - 12.7m Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.1(L) 0.2 (R) frame
0.76 :1 fixed 112-499 0.81m - 5.08m none
1.25 - 1.79 :1 zoom 112-500 1.33m - 11.73m Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.1(L) 0.2 (R) frame
1.73 - 2.27 :1 zoom 112-501 1.83m - 14.9m Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.1(L) 0.2 (R) frame
2.22 - 3.67 :1 zoom 112-502 2.36m - 24.2m Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.1(L) 0.2 (R) frame
3.58 - 5.38 :1 zoom 112-503 3.8m - 35.35m Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.1(L) 0.2 (R) frame
5.31 - 8.26 :1 zoom 112-504 5.59m - 54.8m Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.1(L) 0.2 (R) frame
* Lens focal ranges above are the optimised distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: +/-3%. HighLite Series: +/- 5%. M-Vision Series: +/- 2%. Titan Series: +/-2%, INSIGHT Series: +/-2%,

Lens Mount

Motorised and programmable shift, zoom and focus.
Intelligent Lens Memory with 10 user-definable preset positions (except UST lens).

Mechanical Mounting

Front/Rear Table
Front/Rear Ceiling
Adjustable Front/Rear Feet
Ceiling Mount compatible chassis with 6 off M4*0.7 mounting holes available, Maximum screw length 16mm

Orientation

Table Top or Inverted: Yes
Pointing Up:        Yes
Pointing Down:   Yes
Roll (Portrait):      Yes

Power Requirements

100-240VAC 50/60Hz single phase 6.8A

Power Consumption

583W @ 240VAC (100% Normal mode) 606W @ 100VAC (100% Normal mode) Standby: <0.5W (Network Off), <2W (Network On)

Thermal Dissipation

1988 BTU/Hour @ 240VAC (100% Normal mode) 2070 BTU/Hour @ 100VAC (100% Normal mode)

Fan Noise

Normal mode: 40 dBA typical

Operating/Storage Temperature:

Operating: 0 to 40 °C (32 to 104 °F)
Force ECO over 35°C (95°°F)

Operating Humidity

20%-90% non-condensing

Weight

27.5 kg / 60.6 lbs

Dimensions

L: 598mm x W: 500mm x H:218mm
L: 23.54 inch x W: 19.68 inch x H: 8.58 inch

Safety & EMC Regulations

CB report, cTUVus, CE (European Economic Area), UKCA (United Kingdom), CCC (China), CECP (China Energy Conservation Program), CELP (China Environmental Labeling Program), China RoHS, FCC Class A (USA), FDA, KC (Korea), BSMI (Taiwan), RCM (Australia), IEC 60825-1 Ed3 :2014 - Class 1 Laser Product, IEC EN 62471-5:2015 - Risk Group 2 & 3 (Lens dependent)
