Komplett 2 kanals lomme sett
ACT-312B dual mottager med kombinasjon av 2 x ACT-32TC lommesender.
PS: Hodebøyle mikrofon, lavalier (Mygg) til lommesender bestilles separat, og ligger under tilbehør nederst på siden.
Mipro ACT-312B
- CPU-controlled diversity receiving. "PiloTone & NoiseLock" dual-squelch circuit eliminates signal drop-out and minimizes interference.
- All controls are intuitive and easily operated via electronic buttons to prevent accidental operation.
- Industry’s only RF interference warning indicator for proper adjustments of the SQ level. Increase sensitivity to extend receiving range; decrease the sensitivity to reduce interference.
- Auto Scan function allows quick search for an interference-free working channel. World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
- Output level is pre-adjusted to equal the microphone capsule’s sensitivity. Switchable output levels for the best sound quality options.
- Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.
| Channel | Dual | |
| | Chassis | EIA Standard 19 " 1/2U metal chassis | |
| | Display | Green backlit LCD with automatic bright (working) and dim (standby) displays during performance. | |
| | Frequency Range | UHF 480 ~ 934 MHz (country dependent) | |
| | Bandwidth | 24 MHz | |
| | Deviation | < ± 40 kHz | |
| | Receiving Mode | CPU-controlled diversity receiving | |
| | Sensitivity | 10 dBµV at S/N > 80 dB | |
| | S/N Ratio | > 106 dB(A) | |
| | T.H.D. | < 0.5% @ 1 kHz | |
| | Frequency Response | 50 Hz ~ 18 kHz | |
| | Squelch | “PiloTone & NoiseLock” dual-squelch circuit | |
| | Audio Output | Balanced XLR & Unbalanced Ø 6.3 mm | |
| | Max. Output Level | Balanced: 0 dBV ; Unbalanced: +10 dBV / 0 dBV | |
| | Power Supply | 12 ~ 15 V DC, 1A | |
| | Dimensions (W × H × D) | 210 × 44 × 180 mm / 8.3 × 1.7 × 7.1 " | |
| | Net Weight | Approx. 0.95 kg / 2.1 lbs |
Mipro ACT-32TC- Ultra slim bodypack transmitter.
- On-the-top features include mute button, mini-XLR connector and antenna.
- Backlit LCD displays all operational parameter information.
- World’s first ACT™ function provides precise and rapid frequency sync to the receiver.
- Innovatively designed battery cover allows easy access to operate buttons and prevents accidental operation.
- Mute button with remote-control jack for easy activation of mute function.
- Selectable impedance for microphone or guitar / line inputs. Five selectable gain settings with Auto Limiter to prevent distortion.
- Mini-XLR input with secure screw lock connector.
- Adjustable belt clip allows wearing transmitter in up or down position.
| Housing | Black rugged plastic | |
| | Display | Backlit LCD displays all operational parameter information. | |
| | Frequency Range | UHF 480 ~ 934 MHz (country dependent) | |
| | Bandwidth | 24 MHz | |
| | RF Output Power | 10 mW / 50 mW switchable (country dependent) | |
| | Deviation | < ± 40 kHz | |
| | Spurious Emissions | < -55 dBc | |
| | Gain | 0 dBV | |
| | Dimensions (W×H×D) | 63 × 70 × 25 mm / 2.5 × 2.8 × 1 " | |
| | Net Weight | Approx. 76 g / 2.7 oz | |
| | Battery | 1 × ICR 18500 lithium battery | |
| | Operating Time | Min. 13 hours | |
| | Charger | MP-80 / MP-8 |
Mipro MP-80
The MP-80 is an intelligent 3-in-1 charging station which provides efficient and safe charging. It is designed exclusively for MIPRO rechargeable handheld / bodypack transmitters and batteries. Each station has two charging slots and two storage slots for 2 spare ICR18500 lithium batteries. The MP-80 provides both quick and trickle charging and has a reverse polarity protection circuit to prevent charging errors. Precise charging status is easily read by the user with red (charging) & green (charged) indicators. Multiple charging stations can be easily connected for more charging options.
| Compatible Transmitter | Rechargeable Handheld & Bodypack | |
| | Input Voltage Range | DC 10 ~ 15 V / 1A | |
| | Battery | ICR 18500 3.7 V Li-ion Battery | |
| | Charge Current | Approx. 500 mA by regulation current | |
| | Current Consumption | Approx. 600 mA / 12 V, for two batteries charging at the same time | |
| | Charge Method | Termination by 20% regulation current | |
| | Function | For charging trans-mitters and lith-ium batteries | |
| | Dimension (W × H × D) | 92 × 78 × 158 mm / 3.6 × 3.1 × 6.2 " | |
| | Weight | Approx. 313 g / 11 oz |
